Hustler X-Ride 60" Commercial Zero-Turn Mower w/ Kawasaki FX820 EVO EFI (34.5HP)

Hustler Turf Equipment

$15,799.00
Save $2,236

All Hustler Lawn Mowers

Warranty

5 Year / 1200 Hour (First 2 Years No Hour Limit)
3 Year Limited Engine

Literature

Feel the Power, Not the Bumps.

The new X-Ride is equipped with Custom Ride Technology, an isolated operator suspension platform designed to deliver a comfortable ride for the operator even while on rough terrain. The platform absorbs up to 4 inches of travel and has 5 levels of adjustability for the operator to find their comfort preference all while maintaining the stability on the mower.

Custom Ride Technology

Custom ride technology separates the platform from the frame which pivots along the front footrest. Dial-in comfort with 5-adjustment positions, coil-over-shock suspension system, and 4" of total suspension travel.

Customize the Ride: Personalize the ride with 5 different levels of comfort.
Coil-Over-Shock: Isolated suspension platform has 4" of travel.
Easy to Adjust: Fast toolless one-hand adjustability.
VX4 Deck: Fabricated steel deck engineered to move more grass at high speeds while maintaining cut-quality.

Hustler Turf Accessory Compatibility Chart
Hustler X-Ride Accessories
3 Bag Powered Catcher (must order (1) adapter kit below to complete)	943571
3 Bag Catcher Adapter 60"	128799
Side Fabric Catcher 3.5 Bushel (no adapter needed)	943654
Standard Aluminum Side Catcher 3.3 Bushel (Accelerator)	GCSS
Jumbo Aluminum Side Catcher 5 Bushel (Accelerator)	GCSSXL
Mulching Kit 60"	124314
Flex Forks Kit (cannot use with Bagger installed)	606696
Front Light Bar Kit	129772
Side Light Bar Kit (must purchase 129772 to add side light)	128869
Beacon Kit	110467
Flasher Kit	124554
Hitch Kit	123915
Sand Deck Kit 60"	124137
Steering Lever Extension Kit	122760
Stripe Kit	128600
Rear Anti-Scalp (dual) 60" Deck	113911
Rear Anti-Scalp (single) 60" Deck	113910
Michelin X-Tweel Turf Caster 13 x 6.5-6 Smooth (1 tire)	607444
Michelin X-Tweel Tire 24 x 12N12	607447
Run Flat - tire/wheel assembly 13 x 6.5 x 6	607964

__________________________________________________________________

Specifications

Engine
Engine Manufacturer	Kawasaki FX820 EVO EFI
Engine Horsepower	34.5
Displacement	822cc
Cooling	Air Cooled
Air Cleaner	n/a
Engine Warranty	3 year limited
Drive System
Type	Dual Hydrostatic
Transmission	Hydro-Gear® ZT-5400®
Hydraulic Cooling	Transmission mounted fan
Fuel Capacity	12 gal.
Ground Speed (Fwd)	Up to 13 mph
Parking Brake	Integrated with steering levers
Deck
Cutting Width	60"
Cutting Height	1" to 5.5"
Deck Depth	5.5"
Deck Lift	Foot Operated
Number of Blades	3
Blade Length	20.50"
Blade Tip Speed	18,600
Spindles	Ductile cast iron with steel shaft and sealed ball bearings
Deck Engagement	Electric PTO Clutch
Deck Material	VX4 Deck, Fabricated 7 gauge
Spindle Mounts	Reinforced 7 ga. stamped disc
Impact Trim Area	Front of deck: 11 gauge formed bump bar, Side of deck: 1.5" x .375" steel bar
Construction
Frame	3" X 1.5"x 0.188" steel tubing
Front Axle	Fabricated with tapered roller bearings
Front Caster Wheel	Tapered wheel bearings and debris cap
Front Caster Fork	Fabricated 1/2" steel
General
Seat	Bolstered high back seat with padded arm rests & adjustable back
Cup Holder	Yes
Dimensions
Front Tire (Inches)	13 x 6.5
Drive Tire (Inches)	24 x 12
Weight (lbs)	1570
Height (Inches)	45, 74 w/ ROPS up
Length (Inches)	87
Width w/ Chute Up (Inches)	61
Tire-to-Tire Width (Inches)	56
Productivity (Acres Per Hour)	6.3
Warranty
Warranty	5 Year / 1200 Hour (First 2 Years No Hour Limit)
Dimensions with Catcher
Catcher Style	3-bag
Powered / Non-powered	Powered
Catcher Capacity	12 bushel
Mower Length w/ Catcher	n/a
Mower Width w/ Catcher	n/a
Style 2: Catcher Style	BAC-VAC
Style 2: Powered / Non-Powered	Powered
Style 2: Catcher Capacity	10 bushel
Style 2: Mower Length w/ Catcher	n/a
Style 2: Mower Width w/ Catcher	n/a

If you have any questions about this Hustler X-One 60-inch mower, give us a call during business hours and one of our friendly associates will be happy to assist you. 410-692-5170
